| Structure |
Extra Heavy-Duty Structure |
| MS Plate Thickness |
25 mm Solid STD |
| Product Quality |
Export Quality & Certified Product |
| Main Motor |
5 HP A.C. Motor (Standard Make) |
| AC Drive |
5 HP A.C. Drive (Crompton Make) |
| Bearings |
Standard Bearing (SKF Make) |
| Operating Speed |
180 MPM |
| Brake & Clutch System |
Pneumatic Brake Systems & Clutch Systems for Tightness |
| Pneumatic Cylinders |
6 Nos. Pneumatic Cylinders (Genetic Make) |
| Roller Features |
Banana Bow Roller to remove wrinkles & Pneumatic Pressure Roller |
| Guide Rollers |
2 Nos. Aluminium Guide Rollers |
| Knurling Rollers |
1 No. Knurling Roll with Green Teflon Coating (Heavy Duty 87 mm Diameter) |
| Shafts |
2 Nos. Air Shafts |
| Tie Bar |
3 Nos. Heavy Tie Bar for Balancing |
| Control System |
Control Panel Included |
| Machine Dimensions (L x W x H) |
8.5 ft x 5 ft x 5 ft |
| Machine Weight |
1000 kg (Heavy Duty) |
| Operation Type & Power |
Automatic | Three Phase |
| Safety & Alignment |
Standard Model with All Safety Features & Alignment |
| Model Highlights |
High-Speed Model with High Productivity |
