| Structure |
Extra Heavy-Duty Structure |
| MS Plate Thickness |
2 Nos. MS Plate (25 mm Thickness) |
| Product Quality |
Export Quality & Certified Product |
| Blade Specification |
6" Diameter (2 Nos. HSS Blades) |
| Cutter Alignment |
Motorised Cutter Head Alignment |
| Cutting System |
Automatic Cutting with all Pneumatic Alignment |
| Main Motor |
5 HP A.C. Motor (Standard Make) |
| Control System |
PLC Based Panel with HMI |
| Cover Material |
Nylon Cover |
| Shaft Configuration |
Double Shaft (1 No. Main Shaft) |
| Internal Diameter (ID) |
ID: 76 mm with PP Nylon |
| Bearings |
Standard Bearing (SKF Make) |
| Pneumatic System |
6 Nos. Pneumatic Cylinders (Standard Make) |
| Machine Dimensions (L x W x H) |
7 ft x 4 ft x 4 ft |
| Machine Weight |
1000 kg (Heavy Duty) |
| Operation Type & Power |
Automatic | Three Phase |
| Safety & Alignment |
Safety Guard with all Standard Safety Features & Alignment |
| Model Highlights |
High-Speed Model with High Productivity |
